Affordable every man΄s alarm & control system
Size : 11x7x3 cm
GSM / GPRS dualband modem
Operating voltage: 9 30 V DC
Use, programming and remote controlling by SMS messages
Applicable also for:
Gsm transfer unit, alarms, messages or
Controlling electrical equipment
Independent alarm and controlling unit
4 pcs of measuring, independent inputs for movement detectors, temperature sensors etc
1 Relay for controlling: lights, heating etc
Optional equipment: 4 relays control card RU-4
GSMGate operation available on RU-4 relay card
ALARMS
AND CONTROLS
You can connect practically any sensor, meter or detector to this unit and you can name them all individually as you wish.
voltage 0-20V
voltage 0-5V
current 0-20mA
temperature (alarm from rising, decreasing or both)
resistans
opening top
closing top
resistance loop (movement detectors)
When setting up the measurement value, the system asks for alarm level, the value you give , gives the alarm everytime it is passed. Alarm can be send by SMS message or voice call via gsm network.
Unit can also be equipped with a keylock or number lock for easy controlling ON / OFF state of alarms, alarms can also be connected on and off with SMS
message.
USING
ELECTRICAL EQUIPMENT
By default the unit has 1 pcs of 50V / 10 A relay that can control various machines directly or through a bigger contactor.
Optional relay card has 4 pcs of 230 V AC relays that can directly control 10 Amp machines. 1 Relay can be programmed to do the free of charge GSMGate operation: pulse, on/off or to be on for certain amount of time: 1 182 hours.
The relay card can be installed directly to household electric cabinet and will be easily connected to Centro by normal phone cable.
NOTICE: 230V connections can only be made by certified installer.
